High-Gain SMA Antenna for 4G/5G Data Transmission

Introduction

In the realm of high-performance communication devices, the High-Gain SMA Communication Antennas from CYX stand out for their exceptional quality and efficiency. Whether you're working with GSM, 2.4G, 3G, 4G, or 5G networks, these antennas are designed to enhance data transmission with superior signal strength. This article provides an in-depth look at the specifications, features, usage, and more for the CYX-DX1 model.

Specifications

Type: Cellular Antenna
Brand Name: CYX
Model Number: CYX-DX1
Place of Origin: Guangdong, China
Product Name: High-Gain SMA Communication Antennas
Frequency Range: 700-2700 MHz
Gain: 38 dBi
VSWR (Voltage Standing Wave Ratio): ≤1.5
Input Impedance: 50 Ω
Power Supply: 50W
Connector: SMA internal needle
Antenna Size: 165 x 62 mm

Features

High Gain Performance: With a gain of 38 dBi, this antenna significantly amplifies signal reception and transmission, providing robust connectivity for various communication applications.
Broad Frequency Range: The CYX-DX1 covers a wide frequency range from 700 to 2700 MHz, making it versatile for different cellular networks including GSM, 3G, 4G, and 5G.
Low VSWR: The Voltage Standing Wave Ratio of ≤1.5 ensures minimal signal reflection, which helps in maintaining signal integrity and efficiency.
Durable Construction: Designed for reliability, this antenna is crafted to withstand various environmental conditions, ensuring long-term performance.
Compact Design: With dimensions of 165 x 62 mm, the antenna is compact and easy to integrate into different setups without occupying excessive space.

How to Use

Installation:
- Connect the SMA internal needle connector of the antenna to the corresponding SMA port on your device or equipment.
- Ensure that the antenna is securely fastened and oriented for optimal signal reception.
Positioning:
- Place the antenna in a location that maximizes signal strength. Avoid obstructions and interference sources to achieve the best performance.
Power Supply:
- The antenna supports a power supply of up to 50W. Ensure that your device’s power output does not exceed this limit to prevent damage.
Maintenance:
- Regularly check the antenna for any physical damage or loose connections. Clean the antenna as needed to maintain optimal performance.

What’s in the Box

1 x High-Gain SMA Communication Antenna (CYX-DX1)
1 x SMA Connector (pre-attached)
User Manual

FAQs

Q: What is the primary use of the CYX-DX1 antenna?: A: The CYX-DX1 antenna is designed to enhance signal strength and improve data transmission across various cellular networks, including GSM, 2.4G, 3G, 4G, and 5G.
Q: Can this antenna be used with all types of devices?: A: The antenna is compatible with devices that have an SMA port and can handle the specified frequency range and power supply.
Q: How should I position the antenna for the best performance?: A: Position the antenna in an area with minimal interference and obstruction to maximize signal reception. Ensure it is securely mounted and oriented towards the signal source.
Q: What does the term 'VSWR' mean, and why is it important?: A: VSWR (Voltage Standing Wave Ratio) measures the efficiency of the antenna in transmitting signals. A lower VSWR value indicates better performance and less signal reflection.
Q: Is the CYX-DX1 antenna suitable for outdoor use?: A: Yes, the antenna is designed to be durable and withstand various environmental conditions, making it suitable for both indoor and outdoor applications.
Q: What is the maximum power supply the antenna can handle?: A: The antenna can handle a maximum power supply of 50W.

Conclusion

The CYX-DX1 High-Gain SMA Communication Antenna is a robust and versatile solution for improving signal strength across a wide frequency range. With its high gain, low VSWR, and durable design, it’s an excellent choice for enhancing communication in various settings. Whether for personal or professional use, this antenna promises reliable performance and connectivity.
